Server Integration
| EU platform | tracker.tracksystem.pl (217.23.132.215) | |
| US platform | tracker.us.tracksystem.pl (13.52.37.2) | |
| Server port | 47724 | |
| Integrated on | 19/03/2015 | |
| Revised on | 19/03/2015 |
General information
| Purpose | Vehicle | |
| Installation | Professional |
Housing
| Weight | 190 g (6.7 oz.) | |
| Size | 111x68x24, Lx80x80 mm (4.37×2.68×0.94×3.15×3.15 in) | |
| Waterproof class | IP5X |
GNSS Location
| External antenna (GNSS) | Yes | |
| GPS | Yes |
Connectivity
| Cellular network type | GSM Quad Band | |
| External antenna (Connection) | Yes | |
| Cellular network generation | 2G |
Interfaces
| Number of outputs | 2 | |
| Number of inputs (all types) | 4 | |
| ACC/Ignition input | Yes |
Supported
|
| Discrete inputs | Yes |
Supported
|
| Analog inputs | Yes |
Supported
|
| Outputs | Yes |
Supported
|
Hardware features
| Battery capacity | 750 mAh | |
| Built-in battery | Yes | |
| Emergency button | Yes |
Supported
|
Hardware extras
| Emergency button | Yes |
Supported
|
| Driver ID reading | Yes |
On request
|
Tracking features
| Tracking modes | Continuous |
Events monitoring
| Battery low | Yes |
Supported
|
| Device switched on/off | Yes |
Supported
|
Self monitoring
| Network signal level | Yes |
Supported
|
| GNSS signal level | Yes |
Supported
|
Remote management
| Server connection setup over SMS | Yes |
Supported
|
| Remote device configuration | Yes (over GPRS) |
Supported
|
| Forced GNSS location update over SMS | Yes |
On request
|
Certification
| CE | Yes | |
| FCC | Yes | |
| EAC | Yes |
