Server Integration
| EU platform | tracker.tracksystem.pl (217.23.132.215) | |
| US platform | tracker.us.tracksystem.pl (13.52.37.2) | |
| Server port | 47712 |
General information
| Purpose | Vehicle | |
| Installation | Professional |
Housing
| Weight | 100 g (3.53 oz.) | |
| Size | 104.1×76.8×26.8 mm (4.1×3.02×1.06 in) |
GNSS Location
| Internal antenna (GNSS) | Yes | |
| External antenna (GNSS) | Yes | |
| GPS | Yes |
Connectivity
| Cellular network type | GSM Quad Band | |
| Internal antenna (Connection) | Yes | |
| Cellular network generation | 3G, 4G |
Interfaces
| 1-Wire interface | Yes |
Supported |
| RS232 interface | Yes |
Supported |
| Number of RS232 interfaces | 1 | |
| RS485 interface | Yes |
Supported |
| Number of outputs | 5 | |
| Number of inputs (all types) | 8 | |
| ACC/Ignition input | Yes |
Supported |
| Discrete inputs | Yes |
Supported |
| Analog inputs | Yes |
Supported |
| Outputs | Yes |
Supported |
Hardware features
| Accelerometer | Yes |
Hardware extras
| Driver ID reading | Yes |
On request |
| External temperature sensor reading | Yes |
Supported |
Tracking features
| Tracking modes | Continuous | |
| Smart power consumption | Yes |
Supported |
| Odometer | Yes |
Supported |
| ECO driving | Yes |
Supported |
Events monitoring
| Battery low | Yes |
Supported |
| External power cut off | Yes |
Supported |
| Car crash | Yes |
Supported |
| Towing | Yes |
Supported |
Self monitoring
| Network signal level | Yes |
Supported |
| GNSS signal level | Yes |
Supported |
| External power source voltage | Yes |
Supported |
| Internal battery level | Yes |
Supported |
Remote management
| Server connection setup over SMS | Yes |
Supported |
| Remote device configuration | Yes (over GPRS) |
Supported |
| Remote outputs control | Yes (over GPRS) |
Supported |
| Firmware update OTA | Yes | |
| Forced GNSS location update over SMS | Yes |
On request |
Certification
| EAC | Yes |
